MaxiVideo MV108S

Description

• Autel MaxiVide MV108S digital inspection camera is designed to work with Diagnostic Tablets or PC. It turns your MaxiSys tablet into a video inspection scope, allowing you to examine difficult-to-reach areas normally hidden from sight.
  • Best for difficult-to-reach areas – Autel Inspection Endoscope MV108S can access the desired point of difficult-to-reach car interiors, such as low-light, dark, damp or wet areas, etc. to visualize the images in real time on a screen (paired with Autel diagnostic tablet) for fast.
  • Ultra Small Lens, Super Clear Vision – This video scope camera probe is only  8.5mm, freely access to lots of narrow hard-to-reach areas and places.
  • Wide Applications – Inspect confined areas to locate problems like carbon deposits, blockages, wear, broken components … much faster without disassembling. It can widely be used for inspection in other places inaccessible, e.g. blocked pipe, wall construction, and more.
  • Autel Diagnostic Tablets Compatible – . It works by connecting with all of diagnostic tablets to get the optical image evaluation, detection, and diagnosis.

  Autel MaxiVideo MV108S Specification:

  Imager Head Distance	MV108S: 8.5 mm; MV105S: 5.5 mm
  Camera	MV108S: 2 MP; MV105S: 1 MP
  Resolution	MV108S: 1920 x 1080
  	MV105S: 1280 x 720
  Depth of Field	MV108S:   3cm to 8cm (1.18” to 3.15”)
  	MV105S: 2cm to 10cm (0.79” to 3.94”)
  LED Beads	8 pcs
  Imager Head Cable Length	1 m (39.37″)
  Waterproof Level (Imager Head)	IP67
  Operating Temp.	-10 °C to 70 °C (14 °F to 158 °F )
  Storage Temp.	-10 °C to 70 °C (14 °F to 158 °F )

  Autel MaxiVideo MV108S Packing List

  • 1 x Magnet
  • 1 x Mirror
  • 1 x Hook
